WindRider Sky Eye 40Hz 1080P 40X Zoom Drone Camera
The Sky Eye-40HZ features a 3-axis stabilized gimbal paired with a 1080P 40X zoom camera, tailored for drone inspection, surveillance, search, and rescue missions. Its 40X camera module delivers 1080P full HD video at 30FPS and offers up to 1280X zoom, enabling detailed aerial observation even from long distances.
$0
Share on:
The Sky Eye-40HZ features a 3-axis highly stabilized gimbal paired with a 1080P 40X zoom camera, specially designed for drone inspection, surveillance, search, and rescue missions. This 40X zoom camera module delivers 1080P full HD video streaming at 30FPS and offers up to 1280X zoom, enabling detailed observation from great distances during flight.
Powerful zoom capability
40x optical zoom, 32x digital zoom, 1080P 30fps video streaming.
High-precise 3-axis gimbal with 360-degree rotation
Driven by a specialized sensor, this high-performance 3-axis gimbal achieves a control precision of ±0.02°, guaranteeing exceptionally clear video quality.
Auto-Identity: auto detection and tracking
Utilizing cross-correlation, tracking, and object re-acquisition algorithms, the Sky Eye-40HZ drone zoom camera is capable of maintaining continuous and stable tracking of objects.
Fast deploy and simple gimbal control
The 3-axis drone gimbal features the YDPORT quick attach and detach system for rapid and hassle-free installation. It also supports S.bus, TTL serial interfaces, and Ethernet connections. Using the YDlink gimbal control software, operating the gimbal becomes straightforward and user-friendly.
MAVLINK compatible
The Sky Eye-40HZ drone gimbal supports drones running on PX4 and Ardupilot systems, allowing for seamless integration.
Dimension and weight
Packing list
| 40X zoom camera | |
| Sensor | 1/2.8″ Sony STARVIS CMOS sensor |
| Video Output | Digital: LVDS, Analog: CVBS |
| Video recorded | 1080P/30 MP4 |
| Focal length | 40X optical focal zoom, 4.25-170mm |
| Digital zoom | 32X(1280X with optical zoom) |
| Horizontal viewing angle | D: 73.80°(wede end)~2.16°(tele end) |
| H: 66.35°(wede end)~1.90°(tele end) |
|
| V: 39.98°(wede end)~1.11°(tele end) |
|
| Wide Dynamic | Up to 105dB |
| Auto focus | Less than 1S |
| Min. illumination (50%) | Color(1/30s, 79.5dB): 0.01 lux , BW(1/30s, 79.5dB): 0.002 lux |
| Color DSS(1/1s, 79.5dB): 0.001 lux , BW DSS(1/1s, 79.5dB): 0.0002 lux | |
| Aperture ratio | F1.6 (wide) ~ F4.95 (tele) |
| Gimbal system | |
| Input voltage | 12V |
| Rotate range | Pitch: +45° ~ -164°; Roll: ±45° Yaw: Unlimited |
| Angle amount of jitter | Pitch and roll: ±0.01° Yaw: ±0.02° |
| Control interface | PWM, S.Bus, serial command, and software control via Ethernet |
| Working Current | Static current: 650mA(@12V) |
| Dynamic current: 850mA(@12V) | |
| Mechanical feature |
|
| Total weight (gimbal and camera) | 910g |
| Working temperature | -10° ~ +50° |
