| Test Data | ||||||||
| Propeller | Type | Throttle | Voltage (V) | Current (A) | RPM | Thrust (g) | Power (W) | Efficiency (g/W) |
| T-MOTOR T5147-3 | 1750KV | 20% | 25.2 | 2.1 | 11132 | 227.0 | 53.6 | 4.24 |
| 40% | 25.2 | 6.6 | 16928 | 558.6 | 165.2 | 3.38 | ||
| 60% | 25.1 | 13.7 | 21409 | 910.7 | 342.4 | 2.66 | ||
| 80% | 25.0 | 24.3 | 26122 | 1403.4 | 606.9 | 2.31 | ||
| 100% | 24.8 | 40.5 | 30527 | 1882.5 | 1002.8 | 1.88 | ||
| 1950KV | 20% | 25.2 | 2.6 | 11979 | 257.8 | 65.9 | 3.91 | |
| 40% | 25.2 | 8.6 | 18222 | 635.8 | 215.4 | 2.95 | ||
| 60% | 25.1 | 17.6 | 22540 | 996.7 | 441.3 | 2.26 | ||
| 80% | 24.9 | 30.5 | 27582 | 1559.5 | 758.4 | 2.06 | ||
| 100% | 24.7 | 49.3 | 31401 | 1990.4 | 1215.8 | 1.64 | ||
| 2020KV | 20% | 25.2 | 2.7 | 12105 | 265.1 | 67.5 | 3.93 | |
| 40% | 25.2 | 9.6 | 18557 | 667.1 | 240.2 | 2.78 | ||
| 60% | 25.0 | 19.8 | 22983 | 1054.7 | 494.3 | 2.13 | ||
| 80% | 24.9 | 33.7 | 28069 | 1636.1 | 837.9 | 1.95 | ||
| 100% | 24.6 | 52.7 | 31628 | 2025.5 | 1297.1 | 1.56 | ||
| 2550KV | 20% | 16.8 | 2.9 | 10441 | 188.3 | 49.2 | 3.83 | |
| 40% | 16.7 | 9.2 | 16163 | 492.1 | 153.4 | 3.21 | ||
| 60% | 16.6 | 18.3 | 20173 | 783.9 | 303.6 | 2.58 | ||
| 80% | 16.5 | 31.6 | 24339 | 1199.9 | 520.9 | 2.30 | ||
| 100% | 16.3 | 50.7 | 28250 | 1629.4 | 824.6 | 1.98 | ||
| GF 51466-3 | 1750KV | 20% | 25.2 | 2.1 | 11954 | 222.9 | 52.7 | 4.23 |
| 40% | 25.2 | 6.8 | 18208 | 565.0 | 170.1 | 3.32 | ||
| 60% | 25.1 | 13.2 | 22349 | 877.6 | 330.2 | 2.66 | ||
| 80% | 25.0 | 22.1 | 27050 | 1340.0 | 551.8 | 2.43 | ||
| 100% | 24.8 | 37.7 | 31867 | 1829.2 | 935.5 | 1.96 | ||
| 1950KV | 20% | 25.2 | 2.4 | 12682 | 254.8 | 60.6 | 4.20 | |
| 40% | 25.2 | 8.5 | 19262 | 639.2 | 214.1 | 2.98 | ||
| 60% | 25.1 | 16.1 | 23495 | 981.0 | 404.4 | 2.43 | ||
| 80% | 24.9 | 28.2 | 28763 | 1530.8 | 703.0 | 2.18 | ||
| 100% | 24.7 | 46.9 | 33163 | 1958.3 | 1158.9 | 1.69 | ||
| 2020KV | 20% | 25.2 | 2.6 | 13071 | 260.9 | 65.2 | 4.00 | |
| 40% | 25.2 | 9.3 | 19740 | 654.2 | 233.6 | 2.80 | ||
| 60% | 25.1 | 17.3 | 24135 | 1014.5 | 433.0 | 2.34 | ||
| 80% | 24.9 | 31.1 | 29275 | 1558.0 | 773.5 | 2.01 | ||
| 100% | 24.7 | 51.1 | 33538 | 1973.4 | 1260.4 | 1.57 | ||
| 2550KV | 20% | 16.8 | 2.9 | 11249 | 192.6 | 48.2 | 4.00 | |
| 40% | 16.8 | 9.2 | 17276 | 496.7 | 153.3 | 3.24 | ||
| 60% | 16.7 | 16.9 | 21242 | 779.9 | 282.0 | 2.77 | ||
| 80% | 16.5 | 29.0 | 25404 | 1151.2 | 479.0 | 2.40 | ||
| 100% | 16.3 | 47.6 | 29502 | 1610.7 | 775.6 | 2.08 | ||
